Printed Circuit Boards to simplify components assembly and wiring on your Boeing 737 panels. Our PCBs are designed double sided for enhanced usability and manufactured with the Highest Quality Standards.
You can buy them as a kit or already assembled, soldered and tested.
B737 Printed circuit boards There are 29 products.
Mobiflight - PCB for B737 forward overhead
This is a shield card to be connected on an Arduino board. On the other side these cards connect with the PCBs for B737 forward overhead panels. This way the forward overhead panel can be controlled using Arduino + Mobiflight.
10,00 €In stockMobiflight - PCB for displays (B737...
This card is connected to Arduino shield card on B737 overhead panel section 4, and controls every 7 segments displays on the overhead. Only one this card is need on the forward overhead.
10,00 €In stockMobiflight - PCB for B737 EFIS
This PCB is a patch panel to connect our PCB for B737 EFIS to an Arduino board. Then you can use Mobiflight software to control the EFIS panel.
6,00 €In stockB737 PCB for EFIS (v 4)
Printed circuit board for B737 EFIS panel. High quality fiber-glass double faced PCB with solder mask that makes very easy installing the needed components. Format: kit to be assembled by customer.Same board is valid for pilot and copilot sides.To be directly connected to SimIO boards.
8,00 €In stockMobiflight - PCB for B737 MCP
This PCB is a patch panel to connect our PCB for B737 MCP to an Arduino board. Then you can use Mobiflight software to control the MCP panel.
10,00 €In stockB737 PCB for MCP (v 4.1) (Collins)
Printed circuit board for B737 MCP panel, Collins version. High quality fiber-glass double faced PCB with solder mask that makes very easy installing the needed components. Format: kit to be assembled by customer.To be directly connected to SimIO boards. It includes the circuit to install a concentric knob BANK ANGLE/HDG in an easy way.
20,00 €In stockB737 PCB for MCP (v 4.1) (Honeywell)
Printed circuit board for B737 MCP panel, Honeywell version. High quality fiber-glass double faced PCB with solder mask that makes very easy installing the needed components. Format: kit to be assembled by customer.To be directly connected to SimIO boards. It includes the circuit to install a concentric knob BANK ANGLE/HDG in an easy way.
20,00 €In stockB737 PCB for MCS (v 1)
Printed circuit board for B737 Master Caution System panel. High quality fiber-glass double faced PCB with solder mask that makes very easy installing the needed components. Format: kit to be assembled by customer.Same board is valid for pilot and copilot sides.To be directly connected to SimIO boards.
4,00 €In stockMobiflight - PCB for B737 MCS
This PCB is a patch panel to connect our PCB for B737 MCS to an Arduino board. Then you can use Mobiflight software to control the MCS panel.
6,00 €In stockB737 PCB for DSP (v 1)
Printed circuit board for B737 displays source panel (DSP). High quality fiber-glass double faced PCB with solder mask that makes very easy installing the needed components. Format: kit to be assembled by customer.Same PCB is designed to be used for pilot and copilot sides. And you can use both 8 or 12-positions rotary switches.To be directly connected to...
6,00 €In stockMobiflight - PCB for B737 DSP
This PCB is a patch panel to connect our PCB for B737 DSP panel to an Arduino board. Then you can use Mobiflight software to control the DSP panel.
6,00 €In stockB737 PCB for A/P A/T FMC alerts (v 4.1)
Printed circuit board for B737 A/P A/T FMC panel. High quality double faced PCB with solder mask that makes very easy installing the needed components.Same PCB is designed to be used for pilot or copilot.To be directly connected to SimIO boards.Used for pilot, control of the following inputs:A/P switch A/T switch FMC switch Below G/S switch TEST 1 y 2...
6,00 €In stockMobiflight - PCB for B737 alerts panel
This PCB is a patch panel to connect our PCB for B737 alerts panel (A/P A/T FMC) to an Arduino board. Then you can use Mobiflight software to control the alerts panel.
6,00 €In stockB737 Autobrakes PCB (v 4)
Printed circuit board for B737 autobrakes panel. High quality fiber-glass double faced PCB with solder mask that makes very easy installing the needed components. Includes connectors and elements to build concentric shafts. Format: kit to be assembled by customer.To be directly connected to SimIO boards.
10,00 €In stockMobiflight - PCB for B737 autobrakes panel
This PCB is a patch panel to connect our PCB for B737 autobrakes to an Arduino board. Then you can use Mobiflight software to control the autobrakes panel.
6,00 €In stockB737 PCB for Chrono (digital version) (v 1)
Printed circuit board for B737 chrono/watch panel (digital version). High quality fiber-glass double faced PCB with solder mask that makes very easy installing the needed components. Format: kit to be assembled by customer. Same PCB is designed to be used for pilot and copilot sides.To be directly connected to SimIO boards.
6,00 €In stockB737 PCB for Chrono (mechanical version)...
Printed circuit board for B737 chrono/watch panel (mechanical version). High quality fiber-glass double faced PCB with solder mask that makes very easy installing the needed components. Format: kit to be assembled by customer. Same PCB is designed to be used for pilot and copilot sides.To be directly connected to SimIO boards.
6,00 €In stockB737 PCB for forward overhead
Printed circuit boards for Boeing 737 forward overhead panel. High quality fiber-glass double faced PCB with solder mask that makes very easy installing the needed components. Format: kit to be assembled by customer.To be directly connected to SimIO boards. Available: shiled cards for Arduino+Mobiflight.
10,00 €In stockB737 PCB radios (v 2)
Printed circuit board for B737 radios (COMM, COMM v.2, NAV and ADF). High quality fiber-glass double faced PCB with solder mask that makes very easy installing the needed components. Includes connectors and elements to build concentric shafts. Format: kit to be assembled by customer.To be directly connected to SimIO boards.
10,00 €In stockMobiflight - PCB for B737 radio panels...
This PCB is a patch panel to connect our PCBs for B737 radio panels (COM, NAV or ADF) to an Arduino board. Then you can use Mobiflight software to control these panels. Two radios can be connected to one of these cards.
6,00 €In stockB737 PCB audio (v 2.1)
Printed circuit board for B737 audio panel. High quality fiber-glass double faced PCB with solder mask that makes very easy installing the needed components. Valid for both pilot and copilot sides. Format: kit to be assembled by customer.To be directly connected to SimIO boards.
10,00 €In stockMobiflight - PCB for B737 audio and SELCAL...
This PCB is a patch panel to connect our PCBs for B737 audio and SELCAL panels to an Arduino board. Then you can use Mobiflight software to control these panels.
6,00 €In stockB737 PCB Transponder (v 1.2)
Printed circuit board for B737 transponder panel. High quality fiber-glass double faced PCB with solder mask that makes very easy installing the needed components. Format: kit to be assembled by customer.To be directly connected to SimIO boards.
10,00 €In stockMobiflight - PCB for B737 transponder...
This PCB is a patch panel to connect our PCBs for B737 transponder radio panel to an Arduino board. Then you can use Mobiflight software to control this panel. Trim, Stab trim and printer panels are connected to this card too.
6,00 €In stockB737 PCB cargo fire (v 1.1)
Printed circuit board for B737 cargo fire panel. High quality fiber-glass double faced PCB with solder mask that makes very easy installing the needed components. Format: kit to be assembled by customer.To be directly connected to SimIO boards.
8,00 €In stockMobiflight - PCB for B737 fire...
This PCB is a patch panel to connect our PCBs for B737 fire extinguishers and cargo fire panels to an Arduino board. Then you can use Mobiflight software to control these panels.
6,00 €In stockB737 PCB engines fire extinguishers (v1.1)...
Printed circuit board for Boeing 737 engines fire extinguishers panel. Including the circuits for the leds inside extinguishers levers. High quality fiber-glass double faced PCB with solder mask that makes very easy installing the needed components. Format: kit to be assembled by customer.To be directly connected to SimIO boards.
8,00 €In stockB737 PCB for FMC (v 2.1)
Printed circuit board for Boeing 737, 747 or 777 FMC panel. High quality fiber-glass double faced PCB with solder mask that makes very easy installing the needed components. Format: kit to be assembled by customer.To be directly connected to SimIO boards.
15,00 €In stockMobiflight - PCBs for B737, B777 FMC or...
These PCBs are patch panels to connect our FMC for B737, B777 or A320 MCDU to two Arduino boards. Then you can use Mobiflight software to control the FMC/MCDU.
8,00 €In stock
